Pad Printing Machine for Rulers

  • Model number:GW-RUL-4
  • Printing area:80*400MM
  • Printing speed:1200PCS/HR
  • MOQ:1 unit
  • Payment terms:T/T
  • Package way:plywood case
  • Delivery way:By Ocean
  • Lead time:within 30 workdays after your order confirmation and deposit

Application:

The pad printer machine is specially designed for printing stationery ruler ,it is 3/4 automatic machine, loading by manual--auto printing--auto unloading--auto drying. It is easy to install and operate

Function:

1.PLC control+touch screen

2.with transverse ink cup system,more environmental
3.The X and Y direction of the worktable can be adjusted, the precision can be up to 0.05mm;
4.Big and strong vacuum system
5.Speed: 1200 times / hr
6.with auto unloading system,improve products output
8. Power: 220V 50-60M/Hz
9. The max.length of rulers :300mm
10.Steel plate size: 100*500mm;
11.Ink cup diameter: 82mm;
12.Workstations: 4 pcs;
