4 color automatic pad printing machine for egg tray

New products which listed on April,2015

Application

It’s a automatic pad printer which is specially design for printing plastic & pulp egg box, egg tray. Egg boxes sized can be 4-12pcs egg boxes.

Features
1.PLC touch screen control system for easy operation
2.side guarding design for safety operation
3. Vertical linear conveyor for easy loading and unloading
4.Auto sensor alarm sensor system to minimize the rate of non-conforming product
5.Independent pad moving and ink loading system for easy adjustment and

high precise printing
6.Printing speed and depth can be adjusted to fullfil various requirements
7.Auto unloading conveyor system

Technical Parameter
Ink loading system: open ink tray system
Printing colors: 4 colors
Printing station: 28pcs
Steel plate: 150x300mm
Printing speed: 800pcs/hr
Air pressure: 6 bars
Power: 220/110v, 50/60w

Machine pictures & printing samples
