Desktop Infrared Drying Machine(GW-200H)

  • Model number:GW-200H
  • Machine size:1000*460*465mm
  • MOQ:1 Set
  • Payment terms:T/T,Western Union,Paypal,L/C
  • Package way:by wooden box
  • Delivery way:by sea/air/express
  • Lead time:Within 3-7workdays after get client's deposit

Infrared lamp small tunnel oven for t shirt/sock


It widely used to dry plastic items,electrical part,metal/aluminum items and other different type promotional items after printed by different  printing ink except uv ink.


1.Drying box is totally enclosed,both of inlet/outlet point has shelter door which can be adjusted up and down, effectively shield heating sources leak,like this,it can protect working environment and save energy.
2.Infra-red lamp height can be adjusted.and you can control/adjustment lamps quantity to work
3.The air volume which the blowers supply can be controlled,there is an air volume control valve on the top of heating area,it can adjust wind supply volume.
4.The function selection matching(you can choose this function according to your needing)
5.Electronic digital display intelligent temperature control system and blowing system
6.Machine conveyor belt with quiet varying-speed motor.The speed-adjusting driver and conveyor are Uniform when the dryer is various loads.
7.Conveyor belt and lamps height can be adjustment according kinds of products's size.
Technical Parameter:

Machine size: 1000*460*465mm
Belt width:300mm      Max.conveyoring width:450mm
Max.conveyoring height:100mm( it can be adjustable)
Material of belt: Teflon      Speed:1-5m/minutes
Conveyoring motor wattage: 25W(stepless speed regulation)
Infrared lamps:500W * 6 pcs,total 3 KW.
Power :110V single phase
Wattage of whole machine: 1860W
High temperature:0-150 C
